KC HiLiTES FLEX ERA LED Light Bar - 50-inch Configuration

KC HiLiTES FLEX ERA LED Light Bar - 50-inch Configuration

by KC HiLiTES
$2,799.95

Build a modular KC FLEX ERA light bar in a 50-inch configuration using five linked 10-inch modules. The system can be arranged straight or curved, making it easy to follow the shape of a bumper, rack or overhead mounting surface.

Each FLEX ERA section delivers high-output forward lighting through interchangeable optics and includes an amber backlight for a distinctive low-output accent mode. Because the system is modular, owners can tune overall width, curvature and beam mix rather than being locked into one fixed bar design.

This 50-inch setup is particularly well suited to full-width overhead and large-rack installations where maximum FLEX ERA coverage is the goal. Confirm available mounting space, compatible brackets and electrical capacity before installation.

KC HiLiTES FLEX ERA LED Light Bar - 50-inch Configuration $2,799.95

Universal fit — for compatible bumper, rack or overhead mounting; verify available space, brackets and electrical capacity

Maximum five-section FLEX ERA configuration
39,560-lumen maximum combined output
540 W total full-output demand requires appropriate electrical planning
Full-width format is suited to overhead and large-rack mounting
Five modules provide the greatest freedom to shape an arc across the roofline
Modular 10-inch light sections link into straight or curved configurations
Up to 7,912 raw lumens per 10-inch section
Combo optics support blended short- and mid-range trail illumination
Interchangeable optics allow compatible Spot, Spread or Flood pattern changes
Amber LED backlight provides a distinctive low-output accent mode
Adjustable link geometry follows different bumper and roof profiles
IP68-rated construction protects against dust and water ingress

Manufacturer Part Number: 0295
Fitment: Universal
Product Family: FLEX ERA LED Light Bar
Nominal Length: 50-inch configuration
Section Count: 5
Raw Lumens: 39,560 lm maximum
Power: 540 W full output / 60 W amber backlight
Input Voltage: 9–36 V DC
Beam Options: Combo installed; compatible interchangeable optics
Ingress Protection: IP68
Housing Material: Aluminum alloy
Configuration: Multi-section light bar
Assembly: Required for 20–50 inch configurations
